Round Rods
Grades : MC(Blue/NAT/BLK/Moly/OIL/WAX/ESD-R6/ESD-R10)
Diameter(mm) Tolerance
(mm)
Weight
L 500mm L 1000mm L 300mm
25 +0.5 ~ +3.5 0.29 - -
30 - 0.85 -
35 - 1.15 -
40 - 1.51 -
45 - 1.91 -
50 - 2.36 -
55 - 2.85 -
60 +0.5 ~ +4.0 - 3.39 -
65 - 3.98 -
70 - 4.62 -
75 - 5.30 -
80 - 6.03 -
85 - 6.81 -
90 - 7.63 -
95 - 8.50 -
100 - 9.42 -
110 +1.0 ~ +5.0 - 11.40 -
120 - 13.56 -
125 - 14.72 -
130 - 15.92 -
140 - 18.46 -
150 - 21.20 -
160 +1.0 ~ +6.0 - 24.12 -
170 - 27.22 -
180 - 30.52 -
190 - 34.01 -
200 - 37.68 -
210 +2.0 ~ +9.0 - - 12.46
230 - - 14.95
250 - - 17.66
260 - - 19.10
280 - - 22.16
300 - - 25.43
330 +3.0 ~ +11.0 - - 30.78
350 - - 34.62
380 - - 40.81
400 - - 45.22
450 - - 57.23
470 - - 62.43
500 - - 70.65
Tube
Grades : MC(Blue/NAT/Moly)
±Ô°Ý(mm) Tolerance(mm) Weight(kg/°³)
¿Ü°æ(mm) ³»°æ(mm) ¿Ü°æ(mm) ³»°æ(mm) L 600mm
210 95 +2.0 ~ +9.0 -2.5 ~ -9.5 19.82
145 13.04
230 95 +2.0 ~ +9.0 -3.5 ~ -11.0 24.80
145 18.02
250 95 +2.0 ~ +9.0 -3.5 ~ -13.0 30.22
145 23.44
260 95 +2.0 ~ +9.0 -3.5 ~ -13.0 33.11
145 26.32
195 16.72
280 95 +2.0 ~ +9.0 -3.5 ~ -13.0 39.21
145 32.43
195 22.82
300 145 +2.0 ~ +9.0 -3.5 ~ -13.0 38.98
195 29.38
330 145 +3.0 ~ +11.0 -3.5 ~ -15.5 49.67
195 40.06
245 27.62
350 145 +3.0 ~ +11.0 -3.5 ~ -15.5 57.35
195 47.75
245 35.31
380 145 +3.0 ~ +11.0 -3.5 ~ -15.5 69.73
195 60.12
245 47.69
295 32.43
400 145 +3.0 ~ +11.0 -3.5 ~ -15.5 78.55
195 68.94
245 56.51
295 41.25
450 145 +3.0 ~ +11.0 -3.5 ~ -18.0 102.57
195 92.96
245 80.53
295 65.27
345 47.18
470 145 +3.0 ~ +11.0 -3.5 ~ -18.0 112.97
195 103.36
245 90.93
295 75.67
345 57.58
500 145 +3.0 ~ +11.0 -3.5 ~ -18.0 129.42
195 119.81
245 107.37
295 92.11
345 74.03
