| Round Rods |
| Grades : PEEK(NAT/BLK/CNT-R6) |
| Diameter(mm) |
Tolerance
(mm) |
Weight |
| L 1000mm |
L 3000mm |
| 5 |
+0.1 ~ +0.9 |
0.027 |
0.081 |
| 6 |
0.039 |
0.116 |
| 8 |
+0.2 ~ +1.0 |
0.069 |
0.206 |
| 10 |
0.108 |
0.323 |
| 12 |
0.155 |
0.465 |
| 16 |
0.275 |
0.826 |
| 18 |
0.348 |
1.045 |
| 20 |
+0.2 ~ +1.5 |
0.430 |
1.291 |
| 25 |
0.672 |
2.016 |
| 30 |
0.968 |
2.904 |
| 32 |
1.101 |
3.304 |
| 35 |
1.317 |
3.952 |
| 40 |
1.721 |
5.162 |
| 45 |
2.178 |
6.533 |
| 50 |
2.689 |
8.066 |
| 55 |
3.253 |
9.760 |
| 60 |
+0.5 ~ +2.0 |
3.872 |
11.615 |
| 65 |
+0.5 ~ +2.5 |
4.544 |
13.631 |
| 70 |
5.270 |
15.809 |
| 75 |
6.049 |
18.148 |
| 80 |
6.883 |
20.649 |
| 90 |
8.711 |
26.133 |
| 100 |
+1.0 ~ +3.0 |
10.755 |
32.264 |
| 110 |
13.013 |
39.039 |
| 120 |
15.486 |
46.459 |
| 130 |
18.175 |
54.525 |
| 140 |
21.079 |
63.236 |
| 150 |
24.198 |
72.593 |
| 160 |
27.532 |
82.595 |
| 180 |
34.845 |
104.534 |
| 190 |
38.824 |
116.471 |
| 200 |
43.018 |
129.054 |
|
|
|
| Sheets & Plates |
| Grades : PEEK(NAT/BLK/CNT-R6) |
| Thickness(mm) |
Tolerance
(mm) |
Weight |
| W 610 x L 1000 |
W 610 x L 3000 |
W 1000 x L 3000 |
| 5 |
+0.2 ~ +1.2 |
4.179 |
12.536 |
20.550 |
| 6 |
5.014 |
15.043 |
24.660 |
| 8 |
6.686 |
20.057 |
32.880 |
| 10 |
+0.2 ~ +1.5 |
8.357 |
25.071 |
41.100 |
| 12 |
10.028 |
30.085 |
49.320 |
| 16 |
13.371 |
40.114 |
65.760 |
| 20 |
16.714 |
50.142 |
82.200 |
| 25 |
20.893 |
62.678 |
102.750 |
| 30 |
25.071 |
75.213 |
123.300 |
| 35 |
+0.2 ~ +2.0 |
29.250 |
87.749 |
- |
| 40 |
33.428 |
100.284 |
- |
| 45 |
37.607 |
112.820 |
- |
| 50 |
41.785 |
125.355 |
- |
| 55 |
45.964 |
137.891 |
- |
| 60 |
50.142 |
150.426 |
- |
|
|
